Features
● Two principles of operation are adopted: magnetic induction (ferrous) and eddy current (non-ferrous) to take non-destructive measurements.
● Features two working modes: DIRECT and BATCH & two measuring ways: CONTINUE and SINGLE
● Statistics include the mean, maximum, minimum, test numbers and standard deviation.
● Memory of 10000 data
● Adjustment and Correction: the system error can be corrected by basic calibrating method.
● Alarming function: alarming automatically if measuring values out of pre-set limitation
● Battery Indicator: Low battery indicator
● Printing function: measuring value, statistic value can be printed
● Error warning Function: error warning in display during malfunction
● Manual or automatic shutdown.
| Standard Delivery | |
| Main unit | 1 |
| Probe | 1 |
| Substrate | 1 |
| Calibration foil | 1 |
| Charger | 1 |
| LANCE certificate | 1 |
| Warranty card | 1 |
| Instruction manual | 1 |
| Probe | F1.5 | N1.5 | FN1.5 | F1.5R | F3.5 | FN3.5 | F10 |
| Working principle | Magnetic induction | Eddy current | Magnetic induction
Eddy current |
Magnetic induction | Magnetic induction | Magnetic induction
Eddy current |
Magnetic induction |
| Measuring range | 0-1500 μm | 0-3500 μm | F: 0-3500 μm
N: 0-3000μm |
0-10000 μm | |||
| Minimum resolution | 0.1μm | 0.1μm | 1μm | ||||
| Tolerance | ±(1%H+1) | ±(1%H+3) | ±(1%H+5) | ||||
| Min. curvature radius | Convex 1.5 mm | Convex 5mm | Convex 10mm | ||||
| Min. area diameter | Φ7 mm | Φ10mm | Φ40mm | ||||
| Critical thickness of
the base |
0.5 mm | 0.3mm | F: 0.5mm
N: 0.3mm |
0.5 mm | 0.5 mm | 2mm | |
| Temperature | 10℃ – 30℃ | ||||||
| Humidity | ≤75%RH | ||||||
| Working environment | No strong magnetic field | ||||||
| Power | Li Battery 1 x 3.7V 2200mAh | ||||||
| Dimension | 203.4 x 92.1 x 52.1 (mm) | ||||||
| Weight | 400g (main unit) | ||||||
